It even supports a unique configuration system allowing you to mix and match power input types to match your graphics card. The EVGA PowerLink is a great investment to not only improve the way your PC looks, but also protect your graphics card.

How does POWERLINK work?

In order to achieve its real-time capabilities, POWERLINK relies on a mixed polling and time-slot procedure that allows only one node at a time to transmit data. Each CN then transmits its own data to all other nodes, this time via PollResponse messages.

What is POWERLINK protocol?

POWERLINK Safety is a real-time capable, safety-oriented protocol for machine and factory automation that supports communication cycles in the microsecond range and can be implemented in systems required to provide SIL 3 protection.

What is POWERLINK interface?

The POWERLINK interface board enables the connection of PC host systems to POWERLINK systems via the PCI bus. The interface provides process data to the host via the PCI bus. The board is able to process large quantities of data from systems with up to 240 CNs. It also supports cycle times down to 650 µs.

What does the EVGA PowerLink do?

The EVGA PowerLink™ has one primary function: to make your PC look even more awesome. This adapter allows you to reroute the power inputs for your graphics card, giving you improved case airflow, a lower profile height, and best of all, cleaner wiring setup.

How do I turn off PowerLink EVGA?

The EVGA Powerlink was designed to be easily removable from the graphics card.

1. Squeeze near the base of the connectors.
2. The locking tabs will be released.
3. You can then pull the power link away from the graphics card.

Are powerline WiFi extenders any good?

While a WiFi extender can extend the WiFi signal, there is significant degradation when you use such a product. As far as latency is concerned, powerline adapters are far superior to WiFi extenders. The speeds you’ll get using a powerline adapter are dependent on the quality of your home’s electric wiring.

What is Profinet communication?

Profinet (usually styled as PROFINET, as a portmanteau for Process Field Net) is an industry technical standard for data communication over Industrial Ethernet, designed for collecting data from, and controlling equipment in industrial systems, with a particular strength in delivering data under tight time constraints.

Does EVGA PowerLink work other Gpus?

Other graphics cards may be compatible with the PowerLink, but EVGA cannot officially support or confirm graphics cards manufactured by other companies will work properly with the PowerLink Generally speaking, graphics cards modeled after Nvidia reference designs looking similar to the pictures above may work.

What is a power link used for?

POWERLINK is an Industrial Ethernet solution devised to give users a single, consistent and integrated means for handling all communica- tion tasks in modern automation. It is generally suitable for all conceivable applications in machine and plant engineering as well as for process industry applications.

How does Powerlink communicate in real-time?

In order to achieve real-time capability, POWERLINK resorts to a mixed polling and timeslot procedure that only allows one node at a time to send data. Generally speaking, communication proceeds as it does in an organized roundta- ble conversation, where a moderator prompts participants to make their statements.

What is the communication structure of a Powerlink network?

POWERLINK networks use the following communication structure: one node, e.g. a PLC, motion controller, or industrial PC, is arbitrarily designated to function as the so-called Managing Node (MN), i.e. serve as the “moderator of the conversation.” All other devices operate as Controlled Nodes (CN).

Is Powerlink suitable for centralized or decentralized automation?

Due to its performance characteristics regarding bandwidth, brief cycle times, and the protocol‘s fl exibility, POWERLINK is suitable for both centralized and decentral-style automation concepts.
